On-Trip Mode Transition (From Inspiration to Live Navigation)

Figure 11. On‑Trip Mode (mobile): live map + "Up Next" focus card, Nearby Petals rail, quick navigation/actions, and dynamic discovery banner.

1. Purpose

Provide a seamless shift from planning / inspiration (dashboard, saved petal, seasonal suggestion) into an in-motion experience that preserves itinerary context while surfacing opportunistic nearby petals.

2. Multi-Entry Paths into a Trip

Entry Source	User Action	Initialization Behavior
Seasonal / Promo Card (e.g. Autumn Festival)	Plan This Trip	Seeds Trip Builder with promo petal as Day 1 anchor; derives default date (next weekend)
Saved Petal	Add to Trip (no active trip)	Creates draft trip: petal as first activity; prompts for date range
Recommended Petal (Suggestions rail)	Start Trip	Generates scaffold (cluster of complementary petals) using preference-weighted retrieval
Existing Draft Trip	Continue / Navigate	Enters Trip In Progress state with current day highlighted
Direct Deep Link (shared trip)	Open Link	Loads committed trip; offers "Start Navigation" if today within date range

3. State Transition Overview

State	Source Trigger	Key UI Differences	Caching Notes
Builder (Draft)	New plan initialization	Editable sequence, drag & swap, AI refine chips	Retrieval set + draft generation cache
Trip In Progress (Pre-Commit)	User shifts focus to execution (e.g. presses Navigate)	Day cards + live map + commit bar	Adds live location polling (opt-in)
On‑Trip Mode (Active)	Trip committed + user starts travel	Up Next card pinned, minimized editing, quick actions bar	Location & proximity caches (nearby petals)
Post-Trip Recap	End date passed / user completes	Summary metrics, feedback prompts	Feedback submission flushes popularity deltas

4. Core UI Regions (On-Trip Mode)

Region	Description	Notes
A. Live Map	Real-time position, route polyline (current leg)	Minimizes to picture-in-picture on scroll
B. Up Next Card	Photo, name, distance, ETA, key tags, Start / Navigate button	Collapsible after arrival detection
C. Nearby Petals Rail	Swipeable suggestions within detour threshold (e.g. +10% time)	Excludes current day's locked anchors
D. Newly Discovered Banner	Detected off-route or user-tapped unsaved Petal	One-tap Save or Add to Trip (inserts into current day tail)
E. Quick Actions Bar	Swap Activity, Navigate (Google/Apple/Waze), Save for Later, Refresh Suggestions	Hides when keyboard up
F. Status & Progress Strip	Completed count / remaining, daylight/time warnings	Simple icon + tooltip pattern

5. Live Data & Refresh Strategy

Data	Frequency	Mechanism	Notes
Location	5–10s (dynamic)	Geolocation API / native bridge	Adaptive interval (slower when stationary)
Route ETA	On significant movement or segment change	Provider API (rate-limited)	Fallback to precomputed segment durations
Nearby Petals	Every 2 min or >300m deviation	Geo-filtered hybrid search + tag weighting	Cache window 2–5 min
Weather Alerts (optional)	30 min	Third-party weather API	Show only impactful alerts

6. Personalization & Suggestion Logic

Algorithm (simplified):

1. Base retrieval: geo radius (dynamic by travel mode) + profile favorite_tags.
2. Filter out already scheduled petals + recently dismissed.
3. Diversify by tag cluster if top results homogenous >60%.
4. Apply novelty boost for petals similar to discovered but unsaved.
5. Rank by composite: 0.5 * relevance + 0.2 * proximity_score + 0.2 * novelty + 0.1 * popularity.

7. Telemetry Events

Event	Payload Example
ontrip_view	{ tripId, userId, dayIndex, mode:"drive" }
ontrip_nearby_refresh	{ tripId, count, radiusMeters }
ontrip_navigate_launch	{ tripId, provider:"google", segmentId }
ontrip_discovered_show	{ tripId, petalId }
ontrip_discovered_save	{ tripId, petalId }
ontrip_swap_invoke	{ tripId, fromPetal, toPetal }
ontrip_upnext_arrival	{ tripId, petalId, driftSeconds }
ontrip_feedback_prompt	{ tripId, timing:"end_of_day" }

8. Edge Cases

Scenario	Handling
Offline mid-route	Preserve last route polyline + Up Next details; disable refresh; queue saves
GPS drift / low accuracy	Show accuracy ring; delay arrival detection until stable
No nearby petals	Expand radius once; then show "Enjoy the journey" placeholder
Excess suggestions churn	Debounce refresh; diff highlight only net-new cards
Arrival detection failure	Manual "Mark Arrived" button reveals after ETA + threshold

9. Accessibility

• Up Next card structured as landmark with heading for next destination.
• Nearby rail: list semantics + roving tabindex for swipeable cards.
• High-contrast map overlay icons; avoid color-only encoding for status.
• Motion-reduced mode: disable map auto-pan, provide textual distance updates.

10. Security & Privacy

Concern	Mitigation
Continuous location exposure	Local-only; server gets coarse region unless user opts in to live share
Sensitive companion info in logs	Exclude companion tags from telemetry payloads
Hallucinated dynamic suggestions	Source annotations + retrieval ID hash stored for audit

11. Future Enhancements

• Live collaborative markers (friends en route).
• Energy / battery-aware suggestion filtering (e-bike range).
• Predictive prefetch of likely next 2 segments for offline resilience.
• Passive learning of detour tolerance to tune proximity scoring.

---

Figure 11 added: 2025-09-05 (asset on-trip-mode-mobile.png).

Cross-links: trip-in-progress.md, navigation-picker.md, user-dashboard.md, petal_schema.md.
