Trip In Progress View (Pre-Commit Flex State)

Trip in progress overview with day cards, live map, petals rails, and save action Figure 6. Trip In Progress view showing a nearly finalized weekend plan: day-by-day cards, interactive route map, Petals rails (Saved & Popular), AI refinement suggestions, and a prominent Save Trip action before commit.

1. Purpose

Bridge the gap between active refinement and a committed itinerary. The user perceives the plan as “almost done” yet still malleable for micro-optimizations (timing, insertion, swaps) before locking and sharing.

2. Key UI Regions

Region Description Notes
A. Trip Header Title, date window (editable pre-commit), profile match tags Shows match confidence + weather band summary
B. Day Column(s) Ordered day cards with segment blocks Inline edit for time & duration still enabled
C. Live Map Route polyline + markers with semantic icons Auto-updates on Petal insertion or swap
D. Petals Rail (Saved) User’s previously saved activities Filter + search + drag source
E. Petals Rail (Popular) Community-surfaced high-engagement petals Ranked by recency * popularity score
F. Smart Suggestions Contextual AI improvement chips Each chip triggers a delta retrieval/refine
G. Commit Bar Save Trip, Share (disabled until saved), Export Save transitions to immutable baseline state
H. Activity Insight Hover Quick reason + provenance tooltip Pulled from original generation + RAG citations

3. State Model

State Editable? Map Sync Sharing Notes
InProgress YES (segments, timing, companions) Real-time Disabled Default after choosing a trip
Saving Locked (optimistic) Paused until success Disabled Shows spinner on Commit Bar
Committed NO (structural); notes still editable Stable snapshot + version tag Enabled Version = v1 baseline
Collaborative (future) Limited (suggestion mode) Real-time Link-based Pending share feature

4. Save Trip Flow

  1. User clicks Save Trip.
  2. Frontend assembles normalized itinerary JSON (segments, ordering, POI references, computed aggregates: totalDriveMin, totalRideMin, elevationGain, tag frequencies).
  3. POST /api/trips → returns tripId + version=1.
  4. UI transitions to Committed state; Share/Export buttons enable; delta refinement actions reduce (swap & insert now open a “Create revision?” prompt).

Idempotency

Client sends a clientDraftId to avoid duplicate saves if network retries.

5. Petals Integration

Aspect Behavior
Saved Petals User-curated set (manual saves + post-trip favorites)
Popular Petals Aggregated by region + activity tag (rolling 30d window)
Ranking Signals insert_count, save_count, completion_rate, dwell_ms, implicit boosts (matching user profile tags)
Drag & Drop Shares mechanics defined in Figure 5 (Refinement Detail)
Conflict Check Pre-drop cost: added drive mins + daylight window feasibility

6. AI Suggestion Logic (Pre-Commit)

Trigger Example Chip Scope
Missing meal anchor "Add a scenic lunch stop" Day window (midday slot)
Overloaded afternoon "Shorten final ride before sunset" Affected segments only
Weak diversity "Insert a cultural break" Gap between long homogeneous activities
High idle gap "Fill early evening with light activity" Gap prompt

7. Telemetry (Incremental to Refinement View)

Event Payload
trip_inprogress_view {tripId, userId, entrySource:"refinement|resume"}
trip_save_invoke {tripId, draftHash, segmentCount}
trip_save_success {tripId, version, latencyMs}
trip_save_error {tripId, errorCode}
petal_list_scroll {tripId, list:"saved|popular", scrollDepthPct}
suggestion_chip_show {tripId, chipType}

8. Delta Regeneration Constraints vs Pre-Commit

  • Hard cap on concurrent pending delta tasks: 2
  • If user tries a third: toast “Finish pending adjustments first.”
  • Prevent full itinerary regeneration unless user explicitly clicks “Rebuild day”.

9. Accessibility

  • Distinct ARIA landmarks for Day List, Petals Rails, Suggestion Panel.
  • Drag & drop alternative via: Select Petal → Choose Insertion Slot dialog.
  • Snackbar announcements on save success/failure.

10. Post-Commit Transition (Preview)

After commit: new doc (future) “Share & Collaborate” will define: invite links, suggestion mode, revision diffs (v1 → v2), and annotation layer for proposed changes.

Figure 6 added: 2025-09-05
